ANjo EFW80C10 EndFed 5-Band Wire Antenna


End fed 5 band wire antenna for 80m, 40m, 20m,15m, 10m, short version with wire length 23m. Resonant on specified bands, no tuner needed!

179.00

EFwire, end fed multiband wire antennas require less space than center fed dipoles. The feed point is conveniently located at the end of the antenna and attachment point making the EFwire antennas light and discrete.

EFwire antennas are also great portable multiband antennas that can easily be deployed using trees, glass fibre masts, flag poles etc.

ANjo’s EFwire antennas are resonant, no tuner needed on specified bands!

  • Resonant λ½ or λ½ multiple, therefore no counterpoise or radials needed
  • Feed point at the end/suspension point of the antenna
  • No heavy balun in center of antenna
  • Discrete (stealth) compared to center fed antennas
  • Inconspicuous black PE insulated antenna wire with 750N breaking load
  • Short cable routing directly from the suspension point closer to the radio
  • Protected SO239 UHF socket
  • SWR at resonance frequency ≤ 1.5
  • Bandwidths up to 1,5 MHz for SWR ≤ 2 (depending on the band)

As with any antenna initial tuning might be needed depending on local environment and operating preferences. In some installations you can benefit by installing a RF choke to attenuate common mode noise in the coax shield.

ANjo Antennen – Präzision aus Deutchland!

ANjo EFW80C10 Specifications

Bandwidth at 6m height 10m = 1200 kHz

15m = full band

20m = full band

40m = full band

80m = 100 kHz (shortened)

Length 23m
Max Power 200W PEP at 50% duty cycle, 50W digital modes
Connector SO239 (UHF)
Wire Hard-drawn copper wire 2,8 mm, break load 750N
Clamps & screws Stainless steel
Capsule UV resistant plastic
Weight 1,07 kg
Size (package) 20 x 20 x 10 cm
